A/C EVAPORATOR – Detailed Product Description

Product Name: Automotive A/C Evaporator CoreType: Plate & Fin Evaporator / Parallel Flow EvaporatorFit For: TYT (Toyota), Honda, Nissan, Mitsubishi, Isuzu, Hyundai, Kia, Mercedes‑Benz, BMW

---

1. Core Functions

The evaporator is the key component that produces cold air inside the vehicle:

• Absorbs heat from cabin air and lowers air temperature rapidly
• Converts low‑pressure liquid refrigerant into low‑temperature gas
• Removes moisture from air to achieve dehumidification and defog
• Provides stable cooling performance for the entire HVAC system
• Works with blower motor to deliver consistent cold airflow

---

2. Product Design & Construction

Material & Structure

• Core Material: Full aluminum structure (tubes + fins) for high heat exchange efficiency
• Tubes: Flat multi‑channel aluminum tubes for maximum heat transfer
• Fins: High‑density louvered fins for strong cooling and airflow
• Header / Tank: Reinforced aluminum or durable engineering plastic
• Brackets & Mounting: Precise OE‑matching shape for direct fit
• Inlet & Outlet: Standard OE port size for easy hose connection

Performance Features

• Ultra‑high cooling efficiency
• Fast temperature drop inside the cabin
• Excellent corrosion & salt spray resistance
• Leak‑proof design under high pressure
• Low airflow resistance for strong air volume
• Operating temperature: -40°C to +120°C
• Compatible with R134a and R1234yf refrigerants

---

3. Installation Guide

1. Recover refrigerant from the A/C system before disassembly.
2. Remove the dashboard or glove box to access the evaporator box.
3. Disconnect the expansion valve and refrigerant lines.
4. Open the evaporator housing and remove the old evaporator core.
5. Clean the housing and install the new evaporator.
6. Replace O‑rings, expansion valve, and receiver drier.
7. Reassemble the housing and dashboard.
8. Evacuate the system, charge oil and refrigerant.
9. Test cooling performance and check for leaks.

---

4. Key Partner Factories

Our evaporators are supplied by world‑leading OE manufacturers:

1. DENSO (Japan) – OE supplier for TYT, Honda, Lexus
2. Valeo (France) – OE for European premium vehicles
3. HANON (KOREA) – Global A/C system specialist
4. Guangzhou AC Parts Group (China) – Aftermarket production with IATF 16949
5. THT (GUANGZHOU, China) – Top global replacement brand

---

5. Quality & Warranty

• Certification: ISO 9001, IATF 16949, CE, E‑Mark
• 100% pressure & leakage testing before shipment
• Salt spray & vibration tested for durability
• THT BRAND Warranty: 12 months / 20,000 km

---

6. Market Application

High demand in global aftermarket:

• Southeast Asia
• Middle East
• Russia & CIS
• South America
• Africa
• Repair shops, distributors, fleet operators
